Superhosue High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows

Product Description

Experience High Energy Efficiency NFRC Narrow Frame Aluminium Casement Window
Product Overview
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows

Each column has many different options and customers can combine features to customize their own personalized high energy efficiency narrow frame windows and doors backed by 50 years of industry experience.

Product Specifications
Component Specification Details
Profiles
  1. 6063-T5 high quality thermal break aluminium profile, thickness 1.4-1.6 mm
  2. 6063-T5 high quality non-thermal break aluminium profiles, thickness 1.4-1.6 mm
  3. PVC/UPVC profiles
Glass
  1. Double toughened glazing: 5mm+12A+5mm (A: Air); 5mm+12A+5mm tinted; 5mm+12A+5mm Low-E; 5mm+27A+5mm
  2. Single toughened glazing: 3/4/5/6/8/10/12/15/19/21/6.38/11.76mm
  3. Laminated glazing: 5mm+0.76+5mm, 5mm+0.38+5mm
Hardware
  1. German brand: Roto, Siegenia, Geze
  2. Australian brand: Doric
  3. Chinese brand: Kinlong, Zhenjiang
Mesh
  1. Stainless steel security mesh
  2. Aluminium security mesh
  3. Fiberglass flyscreen
  4. Retractable flyscreen
Finish
  1. Powder coating
  2. Anodized
  3. Electrophoresis
  4. Wood grain
  5. Fluorine carbon coating
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows
High Energy Efficiency NFRC Narrow Frame Aluminium Casement Windows

Professional Guidance & Quality Guarantee

We provide professional suggestions on profile and glazing adoption for first-time window and door buyers. Different regions feature different climatic characteristics, requiring tailored profile or glazing treatments to optimize window longevity, energy absorption, and thermal savings.

Products come with a 10-year quality guarantee. If any window or door experiences issues during the warranty period, exchange options are available.

Frequently Asked Questions (FAQ)
1. What is spectrally selective glazing?

A coated or tinted glazing with optical properties that is transparent to some wavelengths of energy and reflective to others. Typical spectrally selective coatings are transparent to visible light and reflect short-wave and long-wave infrared radiation.

2. What is insulated glass?

This term applies to two or more panes of glass separated by insulation at the edges and air in the centre to provide greater thermal efficiency to a window.

3. What is gas filled glass?

An inert gas, usually argon, is sealed between the panes of glass in a window instead of air. Gas is a better insulator than air, increasing the thermal value of the window.

4. What is AS2047?

AS2047 is the mandatory minimum specification for windows and doors used in Australia, including full compliance with the Glass Standard AS 1288.

5. What performance tests are conducted under AS2047?
The following performance tests are undertaken to verify product compliance:
  • AS 4420.2 Deflection Test: Positive and negative wind pressures are applied to test maximum deflection under wind load.
  • AS 4420.3 Operating Force Test: Verifies that an opening sash opens and closes smoothly without undue effort.
  • AS 4420.4 Air Infiltration Test: Tests window air leakage to ensure energy and acoustic efficiency.
  • AS 4420.5 Water Penetration Resistance Test: Ensures no water leaks through the window structure.
  • AS 4420.6 Ultimate Strength Test: Applies wind pressure up to at least 1.5 times design wind pressure to guarantee structural integrity under extreme wind conditions.
6. What warranty is provided for these windows?

Products come with a comprehensive 10-year quality guarantee covering performance, structure, and functional reliability under proper installation and usage conditions.

For more information about High energy efficiency NFRC narrow frame Aluminium casement windows, please feel free to contact us.
